50L Complete Small-Scale Beer Production System (Microbrewery)
50L Complete Small-Scale Beer Production System (Microbrewery)
Price
7.800,00 €
Availability:
In stock
Out of stock

A turnkey, compact 50L microbrewery system designed for pilot batching, R&D, or nano-scale craft beer production. This all-in-one package includes a 50L mash/lauter/boil tank, two 50L conical fermenters, a malt mill, a complete refrigeration system (100L ice water tank + chiller), and a central digital control cabinet. Constructed from high-grade SUS 304 stainless steel with 80mm polyurethane insulation for thermal efficiency.

SKU
sku-68f9fecfa3ff8
Add to Wishlist
Compare
Language
English
TURNKEY FOOD INDUSTRY PROJECT » COMPLETE SMALL SCALE BEER PRODUCTION LINE

Product Description

Product Details & Technical Specifications

This complete system is configured in five main parts:

1. Mill System (1 SET)

  • Item: Malt Miller
  • Model: Disc mill with adjustable mill degree.
  • Power: 1.2 kW (220V or custom).
  • Features: Low noise, dust-reducing design with internal dust plate.

2. Mash System (Brewhouse)

  • Mash/Lauter/Boiling Tank (1 SET)
    • Effective Capacity: 50L
    • Material: Inner: SUS 304 (2.5mm); Outer: SUS 304 (1.5mm)
    • Insulation: 80mm Polyurethane
    • Features: Top manhole, internal CIP comprehensive cleaning ball, platinum resistance thermometer, sampling port, 0.4u internal polish.
  • Wort Pump (1 SET)
    • Power: 1.1 kW
    • Capacity: 1 T/H
    • Delivery Lift: 25m
  • Plate Heat Exchanger (1 SET)
    • Material: SUS 304
    • Heat Exchange Area: 1 m²
    • Design: Double-guide, two-stage cooling.
    • Ratings: 1.25 Mpa design pressure; 150°C working temperature.

3. Fermentation System

  • Fermenter (2 SETS)
    • Effective Capacity: 50L
    • Material: Inner: SUS 304 (2.5mm); Outer: Stainless steel (1.5mm)
    • Design: 60° conical degree; mushroom sealing head.
    • Insulation: 80mm Polyurethane
    • Cooling: 1.5mm Glycol cooling belt.
    • Features: CIP inlet with cleaning ball, 0.4um internal polish, sampling port, automatic or manual pressure control, platinum resistor thermometer.

4. Refrigeration System

  • Ice Water Tank (1 SET)
    • Effective Capacity: 100L
    • Material: Inner: SUS 304 (2.5mm); Outer: (1.5mm)
    • Insulation: 80mm Polyurethane
    • Cooling Coil: 30m length, ￠19 copper tube.
    • Temp. Range: -30 to 20°C
  • Refrigerator (Chiller Unit) (1 SET)
    • Power: 0.75 kW
    • Cooling Capacity: 1P
    • Refrigerant: R134a or R404a
    • Voltage: 380V or custom.

5. Control System

  • Digital Display Cabinet (1 SET)
    • Material: Stainless steel cover.
    • Function: Provides central control for the brewhouse system, fermenter temperature and pressure, ice water temperature, and ice water pump.
